Custom Steel Truss Roof Warehouse Q235B Q355B Prefabricated Structure

Brand Name : YDX

Model Number : YDX-DS

Certification : CE ISO SGS

Place of Origin : CHINA,QINGDAO

MOQ : 10-10000 square meters

Price : $30.00-$65.00

Payment Terms : T/T

Supply Ability : 10000 tons/month

Delivery Time : 20-30 works days

Packaging Details : Exported standard packing

Insulation : Excellent

Working Scope : Design,Fabrication, Installation

Building Type : Frame

Dimensions : Customers' Requirement

Type : Pre-engineered Building

Windows : Aluminum

Fire Resistance : High

Frame : Steel Structure, Truss

Toughness : Good Toughness

Main Frame : Welded H Steel Beam, Steel Truss

Building : Prefabricated Steel Structure

Corrosion Resistance : High

Height : Customized

Frame Type : Steel Frame

Structure Type : Frame

Earthquake Resistance : Strong

Seismic Design : High Seismic Zone

Installation Time : Short

Aesthetics : Modern

Construction Type : Frame

Cost : Moderate

Product Resistance : Corrosion Resistant

Finish : Galvanized/Painted/Cladding

Roof : Glass Wool, EPS, PU

Product Fire Resistance : Fireproof

Door : Sliding Door or Rolling Door

Contact Now

Heavy Steel Truss Roof Warehouse Q235B Q355B Durable Steel Frame Commercial Warehouse

Product Overview

Steel truss roof structures consist of rods connected by hinges at each end, forming planar or spatial structures with triangular elements. This design primarily subjects members to axial tension or pressure, optimizing material strength. Compared to solid web beams, truss structures offer material savings, reduced dead weight, and increased stiffness for large spans.

Our comprehensive service includes design, fabrication of all structural components (steel columns, beams, purlins, etc.), and complete installation including panels, windows, and doors.

Product Specifications

Steel structure warehouse composition
1. column and beam Material Q355 box or H-shaped steel (painted or galvanized)
2. Steel structure spraying galvanized or painted
3. wall&roof purlin C or Z section steel
4. wall&roof panel colorful corrugated steel sheet ,sandwich panels with EPS, rock wool, fiber glass, PU etc.
5.support steel angle, steel pipe, steel round
6.gutter steel sheet or galvanized steel sheet
7.downpipe pvc pipe
8.door sliding sandwich panel door or rolling metal door
9.window PVC or aluminum alloy windows
10.accessory anchor bolt,high strengthen bolt, normal Bolt, skylight Belts, ventilators, etc
11.Use Our steel structure building have many applications and uses. Workshop, warehouse, office building, multi-story building, hangar,garage, livestock farm,poultry farm ,ect.
12.Advantage 1.Low cost, convenient.
2.Easy assembly and disassembly many times without damage.
3.Widely used in construction site, office building , etc.
4.Good environmental protection.
Steel structure building
1. Primary Framing Box beam column, cross steel column, H-shaped steel column, steel beam
2. Secondary Framing Galvanized Z and C sections purlin
3. Roof and Wall panels Steel sheet and insulated sandwich panels (EPS, fiberglass wool and PU).
4. Steel Decking Floor Galvanized steel decking board
5.Structural subsystem Divider, gutter, awning, partition wall
6.Mezzanines, Platforms Painted or galvanized H beam
7.Other Building Accessories Sliding doors, roll up doors, aluminium windows, louvers, etc.
Service Life 50-70years support steel angle, steel pipe, steel round
Place of Origin Qingdao,Shandong,China Application workshop, warehouse, poultry house,garage etc
Grade Q235B, Q355B or as per customer's need Bolt Grade M20, M16, M14 etc
Connection intensive bolt, ordinary bolt Window PVC steel or aluminum alloy
Downspout PVC pipe or as per customer's request Door sliding or rolling door
Purlin C/Z shape profile Panel EPS/PU/fiber glass/rock wool
Main Frame Welded or hot rolled H-shaped steel, columns, beams, box beams and columns
Drawings & Quotation:
(1) Customized design is welcomed.
(2) In order to promise an accurate quotation and drawings, please let us know the length, width, eave height and local weather.We will quote for you promptly.

Main Steel Frame System

Main structure H section steel Q355, alkyd painting, two primary painting, two finish painting
Roof purlin XZ160*60*20*2.5, galvanized
Wall purlin XZ160*60*20*2.5, galvanized
Intensive bolt Grade 10.9
Turn buckle bolt M20+2, steel Q235, processing
Anchor bolt M24, steel Q235, processing
Ordinary bolt Galvanized bolt M20
Brace nut Galvanized bolt M12

Bracing System

Cross brace Φ20 round steel bar Q235, process and painted (alkyd painting)
Angle brace L50*5 angle steel Q235, process and painted (alkyd painting)
Column bracing Φ25 round steel bar Q235, process and painted (alkyd painting)
Tie bar Φ127*3 steel pipe Q235, process and painted (alkyd painting)
Batter brace Φ32*2.5, Φ12 round steel bar Q235, process and painted (alkyd painting)

Design Services

Our engineering team provides comprehensive design services including:

  • Layout drawings
  • Shop drawings
  • 3D Tekla models
  • Installation drawings

Custom Steel Truss Roof Warehouse Q235B Q355B Prefabricated Structure

Packing and Transportation

All structural components, panels, bolts, and accessories are packed to withstand ocean transportation in 40'HQ containers. Our skilled workers use cranes and forklifts at our factory loading site to ensure damage-free loading.

Custom Steel Truss Roof Warehouse Q235B Q355B Prefabricated Structure

Our Product Range

We specialize in both light and heavy steel structure buildings including:

  • Warehouses
  • Workshops
  • Storage facilities
  • Construction materials
  • High-rise steel office buildings
  • Factories and plants
  • Exhibition halls

Quotation Requirements

To provide an accurate quote, we require the following information:

  • Location: Country and area where the structure will be built
  • Size: Length × Width × Height (mm)
  • Wind load: Maximum wind speed (kn/m², km/h, or m/s)
  • Snow load: Maximum snow height (kn/m² or mm)
  • Anti-earthquake: Required level
  • Brickwall: Needed (1.2m or 1.5m high) or not
  • Thermal insulation: Type required (EPS, fiberglass wool, rockwool, PU sandwich panels) or none
  • Door specifications: Quantity and size (width × height in mm)
  • Window specifications: Quantity and size (width × height in mm)
  • Crane requirements: Quantity, maximum lifting weight (tons), and lifting height (m) if needed


Custom Steel Truss Roof Warehouse Q235B Q355B Prefabricated Structure
